NVIDIA DATA CENTER PLATFORM

The NVIDIA Datacenter Platform accelerates a broad array of workloads from AI training and inference to scientific computing and virtual desktop infrastructure (VDI) applications, with a diverse range of GPUs, all powered by a single unified architecture.

MODEL NO. FORM FACTOR Processor DRIVE BAYS PCI-E SLOT MEMORY
CAPACITY
GPU
SUPPORT
POWER
SUPPLY
ENERGY
STAR EPEAT
G492-Z51 4U AMD EPYC
  • 8 x 3.5″ NVMe/SATA
    4 x SATA/SAS 3.5″ hot-swappable
    HDD/SSD bays
  • 10 x FHFL Gen4 expansion slots for GPU cards
  • 3 x low profile PCIe Gen4 expansion slots
  • 1 x OCP 3.0 Gen4 x16 mezzanine slot in rear side
32 DIMMs 10 3 x 2200W redundant PSUs 80 PLUS Platinum N/A
G482-Z51 4U AMD EPYC
  • 10 x SATA 2.5″ hot-swappable
    HDD/SSD bays
    *On-board 10GbE
  • Up to 8 x PCIe Gen4 GPGPU cards
32 DIMMs 8 3 x 2200W redundant PSUs 80 PLUS Platinum N/A
G482-Z52 4U AMD EPYC
  • 8 x SATA 2.5″ hot-swappable
    HDD/SSD bays
  • 8 x FHFL Gen4 expansion slots for GPU cards
  • 1 x low profile PCIe Gen4 x16 expansion slot
32 DIMMs 8 3 x 2200W redundant PSUs 80 PLUS Platinum N/A
G292-Z44 2U AMD EPYC
  • 8 x SATA 2.5″ hot-swappable
    HDD/SSD bays
  • 8 x PCIe Gen4 expansion slots for GPUs
  • 2 x PCIe Gen4 x16 half-length low-profile slots for add-on cards
16 DIMMs 8 2 x 2200W 80 PLUS Platinum power supply N/A
G492-HA0 4U Intel Ice Lake
  • 4 x 3.5″ or 2.5″ SATA/SAS hot-swappable
    HDD/SSD bays
  • 8 x 3.5″ or 2.5″ SATA/SAS/Gen4 NVMe hot-swappable HDD/SSD bays
  • 10 x PCIe x16 slots (Gen4 x16 bus) for GPUs
  • 1 x PCIe x16 (Gen4 x16 bus) Half-length low-profile slot in rear side
  • 2 x PCIe x16 (Gen4 x16 bus) Half-length low-profile slot in front side
  • 1 x OCP 3.0 mezzanine slot with PCIe Gen4 x16 bandwidth in rear side
32 DIMMs 10 3 x 2200W redundant PSUs 80 PLUS Platinum N/A
G492-H80 4U Intel Ice Lake
  • 12 x 3.5″ or 2.5″ SATA
    hot-swappable
    HDD/SSD bays
    SATA device supported only
  • 8 x PCIe x16 slots (Gen4 x16 bus) for GPUs
32 DIMMs 8 3 x 2200W redundant PSUs 80 PLUS Platinum N/A
G492-HA0 4U Intel Ice Lake
  • 4 x 3.5″ or 2.5″ SATA/SAS
    hot-swappable
    HDD/SSD bays
  • 8 x 3.5″ or 2.5″ SATA/SAS/Gen4 NVMe hot-swappable HDD/SSD bays
  • 2 x SATA DOM supported
  • 10 x PCIe 4.0 x16 slots
  • 3 x PCIe 4.0 x16 half-length low-profile slot
32 DIMMs 10 3 x 2200W redundant PSUs 80 PLUS Platinum N/A
G292-2G0 2U Intel Ice Lake
  • 4 x 2.5″ SATA/SAS hot-swappable HDD/SSD bays
  • 4 x 2.5″ SATA/SAS/Gen4 NVMe hot-swappable HDD/SSD bays
  • 16 x PCIe Gen4 expansion slots for GPUs
  • 2 x PCIe x16 Half-length low-profile slots for add-on cards
24 DIMMs 16
(single slot)
2 x 3200W 80 PLUS Platinum hot-swap power supply N/A
G292-280 2U Intel Ice Lake
  • 4 x 2.5″ SATA/SAS
    hot-swappable
    HDD/SSD bays
  • 4 x 2.5″ SATA/SAS/Gen4 NVMe hot-swappable
    HDD/SSD bays
  • 8 x PCIe Gen4 expansion slots for GPUs
  • 2 x PCIe x16 Half-length low-profile slots for add-on cards
24 DIMMs 8 2 x 3200W 80 PLUS Platinum hot-swap power supply N/A
